Agilent Technologies 8960 Series Reference Guide

509
S:\Hp8960\E1962B CDMA 2000\Pi Release\Reference Guide\Chapters\cdma2000_hpib_setup_afan.fm
SETup:AFANalyzer
SETup:AFANalyzer:EXPandor:RLEVel
SETup:AFANalyzer:EXPandor:STATe
SETup:AFANalyzer:FILTer[:TYPE]
SETup:AFANalyzer:FILTer:TBPass[:FREQuency]
Function Sets/queries the expandor’s reference level to be used when the expandor’s state is set to ON.
Setting Range: 10 mV to 10 V
Resolution: 1 mV
Query Range: 10 mV to 10 V
*RST setting 1 V
Programming Example
OUTPUT 714;”SETUP:AFANALYZER:EXPANDOR:RLEVEL 5V” !Sets expandor reference level to 5 V.
Function Sets/queries whether the expandor is enabled.
Setting Range: 1|ON|0|OFF
Query Range: 1|0
*RST setting 0 (off)
Programming Example
OUTPUT 714;”SETUP:AFANALYZER:EXPANDOR:STATE ON”
Function Sets/queries the filter type for audio measurements.
Setting Range: NONE|TBPass|CMESsage|BPASs50|BPASs300
Query Range: NONE|TBP|CMES|BPAS50|BPAS300
*RST setting NONE
Programming Example
OUTPUT 714;”SETUP:AFANALYZER:FILTER:TYPE BPASS50”
!Selects the 50 Hz to 15 kHz bandpass filter.
Function Sets/queries the center frequency for the 100 Hz tunable bandpass filter (TBPass).
Setting Range: 300.0 to 20000 Hz
Resolution: 0.1
Query Range: 300.0 to 20000 Hz
*RST setting 1000
Programming Example
10 OUTPUT 714;”SETUP:AFANALYZER:FILTER:TBPASS:FREQUENCY 300HZ”
