Agilent Technologies 8960 Series Reference Guide

510
S:\Hp8960\E1962B CDMA 2000\Pi Release\Reference Guide\Chapters\cdma2000_hpib_setup_afan.fm
SETup:AFANalyzer
SETup:AFANalyzer:FREQuency:STATe
SETup:AFANalyzer:PEAK:VOLTage
SETup:AFANalyzer:SDIStortion:FREQuency
SETup:AFANalyzer:SDIStortion:STATe
Function Sets/queries whether the audio frequency measurement is enabled.
Setting Range: 1|ON|0|OFF
Query Range: 1|0
*RST setting 0 (off)
Programming Example
OUTPUT 714;”SETUP:AFANALYZER:FREQUENCY:STATE ON”
Function Sets/queries the expected peak voltage for audio measurements.
Setting Range: 0.001 to 20 Vpk
Resolution: 0.001
Query Range: 0.001 to 20 Vpk
*RST setting 20
Programming Example
10 OUTPUT 714;SETUP:AFANALYZER:PEAK:VOLTAGE 10V”
Function Sets/queries the fundamental frequency setting for the SINAD/distortion measurement.
Setting Range: 100.0 to 10000 Hz
Resolution: 0.1
Query Range: 100.0 to 10000 Hz
*RST setting 1000
Programming Example
10 OUTPUT 714;SETUP:AFANALYZER:SDISTORTION:FREQUENCY 300HZ”
Function Sets/queries whether the SINAD/distortion measurement is enabled.
Setting Range: 1|0N|0|OFF
Query Range: 1|0
*RST setting 0 (off)
Programming Example
10 OUTPUT 714;SETUP:AFANALYZER:SDISTORTION:STATE ON”
