STATus:OPERation:
STATus:OPERation:CALL Condition Register Bit Assignment
The STATus:OPERation:CALL register bits will be used to indicate status of processes that occur during
normal call processing operations.
Program Examples - STATus:OPERation:CALL
OUTPUT 714;”STATUS:OPERATION:CALL:EVENT?” !Queries the Operation Call Event !Register.
OUTPUT 714;”STATUS:OPERATION:CALL:CONDITION?” !Queries the Operation Call Condition Register.
OUTPUT 714;”STATUS:OPERATION:CALL:ENABLE 4”
!Sets the Operation Call Enable Register for bit 2.
OUTPUT 714;”STATUS:OPERATION:CALL:NTR 4” !Sets the Negative Transition Register for bit 2.
OUTPUT 714;”STATUS:OPERATION:CALL:PTR 256” !Sets the Positive Transition Register for bit 8.
Bit
Number
Binary
Weighting
Condition Description
15 32768 Not Used. Defined by SCPI. This bit is always 0.
14 16384 Reserved for future use. This bit is always 0.
13 8192 Reserved for future use. This bit is always 0.
12 4096 Reserved for future use. This bit is always 0.
11 2048 Reserved for future use. This bit is always 0.
10 1024 Reserved for future use. This bit is always 0.
9 512 TA2000 Summary bit This bit is the summary message bit for the
STATus:OPERation:CALL:TA2000 register.
8 256 CDMA Summary bit This bit is the summary message bit for the
STATus:OPERation:CALL:CDMA register.
7 128 DIGital2000 Summary bit This bit is the summary message bit for the
STATus:OPERation:CALL:DIGital2000 register.
6 64 DIGital95 Summary bit This bit is the summary message bit for the
STATus:OPERation:CALL:DIGital95 register.
5 32 TA136 Summary bit This bit is the summary message bit for the
STATus:OPERation:CALL:TA136 register.
4 16 DIGital136 Summary bit This bit is the summary message bit for the
STATus:OPERation:CALL:DIGITAL136 register.
3 8 AMPS Summary bit This bit is the summary message bit for the
STATus:OPERation:CALL:AMPS register.
2 4 GSM Summary bit This bit is the summary message bit for the
STATus:OPERation:CALL:GSM register.
1 2 COMMon Summary bit This bit is the summary message bit for the
STATus:OPERation:CALL:COMMon register.
0 1 Extension Bit This bit is always 0.
