STATus:QUEStionable

Program Example - STATus:QUEStionable:ERRors:COMMon Register Bit Assignments

OUTPUT 714;”STATUS:QUESTIONABLE:ERRORS:COMMON:EVENT?” !Queries and clears the Questionable

!Errors Common Event Register

OUTPUT 714;”STATUS:QUESTIONABLE:ERRORS:COMMON:CONDITION?” !Queries the and clears the

!Questionable Errors

!Common Condition Register

OUTPUT 714;”STATUS:QUESTIONABLE:ERRORS:COMMON:ENABLE 1024” !Sets the Questionable

!Errors Common Enable

!Register for bit 10

OUTPUT 714;”STATUS:QUESTIONABLE:ERRORS:COMMON:NTRANSITION 2” !Sets the Questionable Errors

!Common Negative Transition

!Register for bit 1

OUTPUT 714;”STATUS:QUESTIONABLE:ERRORS:COMMON:PTRANSITION 2” !Sets the Questionable Errors

!Common Positive Tranasition

!Register for bit 1

4 16 +400 Errors The condition bit is pulsed to a 1 and immediately

back to 0 if an error in the +400 to +499 range

occurs. After setting the Positive Transition Filter

and the Negative Transition Filter you can query

the Event Register to find out which of these errors

occurred.

3 8 +300 Errors The condition bit is pulsed to a 1 and immediately

back to 0 if an error in the +300 to +399 range

occurs. After setting the Positive Transition Filter

and the Negative Transition Filter you can query

the Event Register to find out which of these errors

occurred.

2 4 +200 Errors The condition bit is pulsed to a 1 and immediately

back to 0 if an error in the +200 to +299 range

occurs. After setting the Positive Transition Filter

and the Negative Transition Filter you can query

the Event Register to find out which of these errors

occurred.

1 2 +100 Errors The condition bit is pulsed to a 1 and immediately

back to 0 if an error in the +100 to +199 range

occurs. After setting the Positive Transition Filter

and the Negative Transition Filter you can query

the Event Register to find out which of these errors

occurred.

0 1 Extension Bit This bit is always 0.

Bit

Number

Binary

Weighting

Condition Description
