STATus:QUEStionable
STATus:QUEStionable:HARDware Condition Register Bit Assignment
The STATus:QUEStionable:HARDware register bits give an indication that the data/signals currently being
acquired or generated are of questionable quality.
Program Example - STATus:QUEStionable:HARDware Condition Register Bit Assignment
OUTPUT 714;”STATUS:QUESTIONABLE:HARDWARE:EVENT?” !Queries and clears the Questionable
!Hardware Event Register
OUTPUT 714;”STATUS:QUESTIONABLE:HARDWARE:CONDITION?” !Queries and clears the Questionable
!Hardware Condition Register
OUTPUT 714;”STATUS:QUESTIONABLE:HARDWARE:ENABLE 1024” !Sets the Questionable
!Hardware Enable
!Register for bit 10
OUTPUT 714;”STATUS:QUESTIONABLE:HARDWARE:NTRANSITION 2” !Sets the Questionable
!Hardware Negative Transition Filter
!Register for bit 1
OUTPUT 714;”STATUS:QUESTIONABLE:HARDWARE:PTRANSITION 2” !Sets the Questionable
!Hardware Positive Transition Filter
!Register for bit 1
Bit
Number
Binary
Weighting
Condition Description
15 32768 Not Used. Defined by SCPI. This bit is always 0.
14 16384 Reserved for future use. This bit is always 0.
13 8192 Reserved for future use. This bit is always 0.
12 4096 Reserved for future use. This bit will always be 0.
11 2048 Reserved for future use. This bit will always be 0.
10 1024 Reserved for future use. This bit will always be 0.
9 512 Reserved for future use. This bit will always be 0.
8 256 Reserved for future use. This bit will always be 0.
7 128 Reserved for future use. This bit will always be 0.
6 64 Reserved for future use. This bit will always be 0.
5 32 Reserved for future use. This bit will always be 0.
4 16 Power-up Self Test(s) Failed This bit will be a 1 if the power-up self tests failed.
3 8 Reserved for future use. This bit will always be 0.
2 4 Reserved for future use. This bit will always be 0.
1 2 Reserved for future use. This bit will always be 0.
0 1 Extension Bit. This bit will always be 0.
