642
S:\Hp8960\E1962B CDMA 2000\Pi Release\Reference Guide\Chapters\cdma2000_hpib_system_correction.fm
SYSTem:CORRection
SYSTem:CORRection:GAIN
SYSTem:CORRection:POINts
Function Sets/queries the up to 20 comma separated offset gain values in units of dB. Each gain value
corresponds with a frequency setting. See “SYSTem:CORRection:FREQuency” .
See “Measurement Related Configuration” on page 81.
The units, dB, are optional. If no units are specified, units default to dB.
Sending a null list (no values) sets the state of all offsets to Off.
Setting Range: 0 to 20 values between
−100 to +100
Resolution: 0.01
Query Range: 1 to 20 values between
−100 to +100, and NAN (9.91E+37)
Resolution: 0.01
Factory
Setting
Offsets 1 through 20, are set to 0.00 dB, state is set to off
Programming Example
OUTPUT 714;"SYSTEM:CORRECTION:GAIN -3.12,-3.68,-4.23"
!Sets up to 20 comma separated offset values.
OUTPUT 714;"SYSTEM:CORRECTION:GAIN"
!Sets the state for all frequencies and offsets to Off.
Function Query returns the number of offsets that are in their On state when the RF IN/OUT Amplitude
Offset State is also set to On.
See “Measurement Related Configuration” on page 81.
Query Range: 1 to 20, and NAN (9.91E+37)
Resolution: 1
Programming Example
OUTPUT 714;"SYSTEM:CORRECTION:POINTS?"
!Returns the number of frequencies and offsets with their state set to On.
