Forward Channel Description
Data Patterns/Rates
All data patterns are 2
15-1
PRBS.
Data rates available on the FCH (fundamental channel) depend on the RC (radio configuration) and include:
FCH data rates can be set using the “CALL:TRAFfic” commands.
Data rates available on the SCH (supplemental channel) also depend on the RC (radio configuration) and
include:
SCH data rates can be set using the “CALL:SCHannel” commands.
Table 22. Forward FCH Data Rates
RC1 RC2 RC3 RC4 RC5
1.2 kbps 1.8 kbps 1.5 kbps 1.5 kbps 1.8 kbps
2.4 kbps 3.6 kbps 2.7 kbps 2.7 kbps 3.6 kbps
4.8 kbps 7.2 kbps 4.8 kbps 4.8 kbps 7.2 kbps
9.6 kbps 14.4 kbps 9.6 kbps 9.6 kbps 14.4 kbps
Table 23. Forward SCH Data Rates
RC3 RC4 RC5
9.6 kbps 9.6 kbps 14.4 kbps
19.2 kbps 19.2 kbps 28.8 kbps
38.4 kbps 38.4 kbps 57.6 kbps
76.8 kbps 76.8 kbps 115.2 kbps
153.6 kbps 153.6 kbps 240.4 kbps
NA 307.2 kbps NA
