154 Chapter 4

Calibration

Unknown Thru Calibration

Procedure to select the standard type and define the standard factor

Step 1. Press .

Step 2. Press Modify Calkit.

Step 3. Press Define STDs.

Step 4. Press {Defined Name}.

Step 5. Press STD Type.

Step 6. Press Unknown Thru.

Step 7. Press Offset Delay, then enter approximate offset delay value of the unknown thru

standard.

Procedure to define the unknown thru

Step 1. Press .

Step 2. Press Modify Calkit.

Step 3. Press Specify CLSs.

Step 4. Press Thru.

Step 5. Press Set All.

Step 6. Press {Defined Name}.

NOTE Different unknown thru can be used for different ports.

Procedure to perform the unknown thru

Step 1. Press .

Step 2. Press Calibrate.

Step 3. Press n-Port Cal

Step 4. Press Transmission.

Step 5. Press {Defined Name} to execute mechanical unknown thru calibration.

Step 6. Complete Reflection, and Isolation (optional) for n-full port calibration.

*1.The 1-port calibration is not available.
