Chapter 12 409

Optimizing Measurements

Reducing Measurement Error in High Temperature Environments

12. Optimizing Measurements

Reducing Measurement Error in High Temperature

Environments

The E5070B/E5071B is designed to obtain the best measurement accuracy at the ambient

temperature range of 23°C ± 5°C. The high temperature measurement mode of the

E5070B/E5071B reduces measurement error (drift error) at an ambient temperature of

28°C to 33°C.

NOTE The high temperature measurement mode must be turned off when the analyzer is used at

an ambient temperature below 28°C. Otherwise, the measurement accuracy may be

degraded.

Procedure

Step 1. Press .

Step 2. Press Service Menu.

Step 3. Press High Temperature to turn ON/OFF the high temperature measurement mode.
