Chapter 15 491

Measurement Examples

Measuring the SAW Bandpass Filter Using the Segment Sweep

15. Measurement Examples

5. Connect the DUT

The DUT is connected across test ports 1 and 2.

Figure 15-4 Connecting the DUT

6. Execute the Measurement

A trigger is applied to perform the measurement.

Setup Description Key Operation

Trigger mode: Single

- Single (Or Continuous)

7. Define the Setup for Display

The choice is made between frequency base and order base as the segment display mode.

Setup Description Key Operation

Segment display: Frequency base or order base

- Segment Display -

Frequency Base | Order Base
