508 Chapter 15

Measurement Examples

Measuring the Deviation from a Linear Phase

6. Measure the Deviation from a Linear Phase

The statistics data is used to read the deviation from a linear phase (peak-to-peak) (Figure

15-24).

Setup Description Key Operation

Executing the auto scale

- Auto Scale

Displaying the statistics data

- Statistics (Turn it ON.)

Figure 15-24 Measuring the deviation from a linear phase
