Calibration Menu
D. Softkey Functions
Calibration Menu
Key Operation Function SCPI Command
Displays softkeys for setting and executing calibrations.
Correction Enables or disables error correction.
:SENS{1-16}:CORR:STAT
Calibrate Displays softkeys for selecting calibration options.
Response (Open) Displays softkeys for selecting options for response calibration using the OPEN standard.
Select Port Displays softkeys for selecting a test port.
1 Selects test port 1.
:SENS{1-16}:CORR:COLL:METH:OPEN 1
2 Selects test port 2.
:SENS{1-16}:CORR:COLL:METH:OPEN 2
3
*1
Selects test port 3.
:SENS{1-16}:CORR:COLL:METH:OPEN 3
4
*2
Selects test port 4.
:SENS{1-16}:CORR:COLL:METH:OPEN 4
Cancel Returns to the softkey display screen one level higher.
Open Executes a response calibration using the OPEN standard on the
test port selected in the
Select Port menu. This calibration is
effective for eliminating response tracking errors.
:SENS{1-16}:CORR:COLL:OPEN
Load (Optional) Executes an isolation calibration using the LOAD standard on the
test port selected in the
Select Port menu. This calibration is
effective for eliminating directivity errors.
:SENS{1-16}:CORR:COLL:LOAD
Done Terminates a calibration process and calculates the calibration
coefficients.
:SENS{1-16}:CORR:COLL:SAVE
Cancel Displays softkeys for canceling a calibration.
OK Cancels a calibration process and clears the measurement data of
standard.
:SENS{1-16}:CORR:COLL:CLE
Cancel Returns to the softkey display screen one level higher.
Return Returns to the softkey display screen one level higher.
Response (Short) Displays softkeys for selecting options for a response calibration using the SHORT standard.
Select Port Displays softkeys for selecting a test port.
1 Selects test port 1.
:SENS{1-16}:CORR:COLL:METH:SHOR 1
2 Selects test port 2.
:SENS{1-16}:CORR:COLL:METH:SHOR 2
3
*1
Selects test port 3.
:SENS{1-16}:CORR:COLL:METH:SHOR 3
4
*2
Selects test port 4.
:SENS{1-16}:CORR:COLL:METH:SHOR 4
Cancel Returns to the softkey display screen one level higher.
Short Executes a SHORT calibration on the test port selected in the Select
Port
menu. This calibration is effective for eliminating reflection
tracking errors.
:SENS{1-16}:CORR:COLL:SHOR
Load (Optional) Executes an isolation calibration using the LOAD standard on the
test port selected in the
Select Port menu. This calibration is
effective for eliminating directivity errors.
:SENS{1-16}:CORR:COLL:LOAD
Done Terminates a calibration process and calculates the calibration
coefficients.
:SENS{1-16}:CORR:COLL:SAVE
Cancel Displays softkeys for canceling a calibration.
OK Cancels a calibration process and clears the measurement data of
standard.
:SENS{1-16}:CORR:COLL:CLE
Cancel Returns to the softkey display screen one level higher.
Return Returns to the softkey display screen one level higher.
