Agilent Technologies ENA Series

718 Appendix D
Softkey Functions
System Menu
System Menu
Key Operation Function SCPI Command
Displays softkeys for performing limit tests and accessing control and management functions on the analyzer.
Print Outputs the current screen to a printer.
:HCOP
Abort Printing Aborts printing.
:HCOP:ABOR
Printer Setup Opens a dialog box for setting up the printer.
None
Invert Image Inverts the colors of the screen display.
:HCOP:IMAG
Dump Screen Image Opens a dialog box for saving the screen image in BMP (Windows or
OS/2 bitmap) format.
:MMEM:STOR:IMAG
Multiport Test Set
Setup
Displays softkeys for setting the E5091A control.
Test Set 1 Displays the model selected for test set 1.
Select Test Set Displays the selected model.
E5091_9 Selects the 9-port model (E5091A-009).
:SENS{1-16}:MULT1:NAME E5091_9
E5091_13 Selects the 13-port model (E5091A-016).
:SENS{1-16}:MULT1:NAME E5091_13
E5091_16 Selects the 16-port model (E5091A-016).
:SENS{1-16}:MULT1:NAME E5091_16
Cancel Returns to the softkey display screen one level higher.
Control Enables/disables control of the E5091A.
:SENS{1-16}:MULT1:STAT
Property Enables/disables the display of the E5091A properties.
:SENS{1-16}:MULT1:DISP
Port 1 Displays softkeys for selecting a test port of the E5091A to which you want to connect port 1.
A1 Selects test port A1.
:SENS{1-16}:MULT1:PORT1 A1
A2
*1
Selects test port A2.
:SENS{1-16}:MULT1:PORT1 A2
A3
*1
Selects test port A3.
:SENS{1-16}:MULT1:PORT1 A3
A4
*1
Selects test port A4.
:SENS{1-16}:MULT1:PORT1 A4
A
*1
Selects test port A.
:SENS{1-16}:MULT1:PORT1 A
T1 Selects test port T1.
:SENS{1-16}:MULT1:PORT1 T1
T2
*1
Selects test port T2.
:SENS{1-16}:MULT1:PORT1 T2
T3
*1
Selects test port T3.
:SENS{1-16}:MULT1:PORT1 T3
Cancel Returns to the softkey display screen one level higher.
Port 2 Displays softkeys for selecting a test port of the E5091A to which you want to connect port 2.
B1
*1
Selects test port B1.
:SENS{1-16}:MULT1:PORT2 B1
B2
*1
Selects test port B2.
:SENS{1-16}:MULT1:PORT2 B2
B3
*1
Selects test port B3.
:SENS{1-16}:MULT1:PORT2 B3
B4
*1
Selects test port B4.
:SENS{1-16}:MULT1:PORT2 B4
T1 Selects test port T1.
:SENS{1-16}:MULT1:PORT2 T1
T2 Selects test port T2.
:SENS{1-16}:MULT1:PORT2 T2
T3
*1
Selects test portT3.
:SENS{1-16}:MULT1:PORT2 T3
T4
*1
Selects test port T4.
:SENS{1-16}:MULT1:PORT2 T4
Cancel Returns to the softkey display screen one level higher.
