692 Appendix D
Softkey Functions
Format Menu
Format Menu
Key Operation Function SCPI Command
Displays softkeys for setting up data formats.
Log Mag Displays traces in a rectangular display format with log magnitude (dB) on
the Y-axis and frequencies on the X-axis (log magnitude format).
:CALC{1-16}:SEL:FORM MLOG
Phase Displays traces in a rectangular display format with phase (-180× to +180×)
on the Y-axis and frequencies on the X-axis (phase format).
:CALC{1-16}:SEL:FORM PHAS
Group Delay Displays traces in a rectangular display format with group delay (s) on the
Y-axis and frequencies on the X-axis (group delay format).
:CALC{1-16}:SEL:FORM GDEL
Smith Displays softkeys for setting up smith chart.
Lin / Phase Displays traces in Smith chart format. The marker response values are
linear magnitude and phase (×).
:CALC{1-16}:SEL:FORM SLIN
Log / Phase Displays traces in Smith chart format. The marker response values are log
magnitude (dB) and phase (×).
:CALC{1-16}:SEL:FORM SLOG
Real / Imag Displays traces in Smith chart format. The marker response values are the
real and imaginary parts.
:CALC{1-16}:SEL:FORM SCOM
R + jX Displays traces in Smith chart format. The marker response values are
resistance (W) and reactance (W).
:CALC{1-16}:SEL:FORM SMIT
G + jB Displays traces in Smith chart format. The marker response values are
conductance (S) and susceptance (S).
:CALC{1-16}:SEL:FORM SMGB
Cancel Returns to the softkey display screen one level higher.
Ploar Displays softkeys for setting up polar format.
Lin / Phase Displays traces in polar format. The marker response values are linear
magnitude and phase (×).
:CALC{1-16}:SEL:FORM PLIN
Log / Phase Displays traces in polar format. The marker response values are log
magnitude (dB) and phase (×).
:CALC{1-16}:SEL:FORM PLOG
Real / Imag Displays traces in polar format. The marker response values are the real and
imaginary parts.
:CALC{1-16}:SEL:FORM POL
Cancel Returns to the softkey display screen one level higher.
Lin Mag Displays traces in a rectangular display format with linear magnitude on the
Y-axis and frequencies on the X-axis (linear magnitude format).
:CALC{1-16}:SEL:FORM MLIN
SWR Displays traces in a rectangular display format with SWR (standing wave
ratio) on the Y-axis and frequencies on the X-axis (SWR format).
:CALC{1-16}:SEL:FORM SWR
Real Displays traces in a rectangular display format with the real part on the
Y-axis and frequencies on the X-axis (real format).
:CALC{1-16}:SEL:FORM REAL
Imaginary Displays traces in a rectangular display format with the imaginary part on
the Y-axis and frequencies on the X-axis (imaginary format).
:CALC{1-16}:SEL:FORM IMAG
Expand Phase Displays traces in a rectangular display format with expanded phase (×) on
the Y-axis and frequencies on the X-axis (expanded phase format).
:CALC{1-16}:SEL:FORM UPH
Positive Phase Displays traces in a rectangular display format with phase (0× to +360×) on
the Y-axis and frequencies on the X-axis (positive phase format).
:CALC{1-16}:SEL:FORM PPH
Return Returns to the “E5070B/E5071B Menu (Top Menu)” on page 646.
