Agilent Technologies ENA Series

714 Appendix D
Softkey Functions
Stimulus Menu
Stimulus Menu
Key Operation Function SCPI Command
Sets the lowest frequency for sweeps.
Also displays a menu (Stimulus Menu) for defining the sweep range.
:SENS{1-16}:FREQ:STAR
Start Sets the starting frequency for sweeps.
:SENS{1-16}:FREQ:STAR
Stop Sets the ending frequency for sweeps.
:SENS{1-16}:FREQ:STOP
Center Sets the center frequency of the sweep range.
:SENS{1-16}:FREQ:CENT
Span Sets the frequency span for sweeps.
:SENS{1-16}:FREQ:SPAN
Return Returns to the “E5070B/E5071B Menu (Top Menu)” on page 646.
Sets the ending frequency for sweeps.
Also displays the Stimulus Menu same as .
:SENS{1-16}:FREQ:STOP
Sets the center frequency of the sweep range.
Also displays the Stimulus Menu same as .
:SENS{1-16}:FREQ:CENT
Sets the frequency span for sweeps.
Also displays the Stimulus Menu same as .
:SENS{1-16}:FREQ:SPAN
