Agilent Technologies ENA Series

602 Appendix A
Manual Changes
Manual Changes
o Assignable x-axis such as RF+LO, RF-LO, and LO-RF frequencies for each active
trace
o Conjugation for converting vector mixer measurement parameters
o 7 mm calibration kits such as 85031B and 85050C/D
o Calibration data and calibration coefficient clear functions
Change 6
Use Following specifications for the serial prefix MY422.
Table A-3
Description Specification Supplemental Information
Damage Level
300 kHz to 8.5 GHz RF +20 dBm,
±14 VDC (Source attenuator = 0
dB),
±25 VDC (Source attenuator = 5
dB or more), typical
Change 5
Use Following specifications for the serial prefix MY421 and JP1KK.
Table A-4 System Dynamic Range
Description Specification Supplemental Information
System Dynamic Range
*1*2
300 kHz to 3 MHz IF bandwidth = 3 kHz 85 dB
3 MHz to 1.5 GHz 95 dB 98 dB
1.5 GHz to 4 GHz 97 dB 100 dB
4 GHz to 6 GHz 93 dB 95 dB
6 GHz to 7.5 GHz 88 dB 91 dB
7.5 GHz to 8.5 GHz 81 dB 84 dB
300 kHz to 3 MHz IF bandwidth = 10 Hz 110 dB
3 MHz to 1.5 GHz 120 dB 123 dB
1.5 GHz to 4 GHz 122 dB 125 dB
4 GHz to 6 GHz 118 dB 120 dB
6 GHz to 7.5 GHz 113 dB 116 dB
7.5 GHz to 8.5 GHz 106 dB 109 dB
