Chapter 15 531

Measurement Examples

Executing Power Calibration

15. Measurement Examples

6. Connecting Power Sensor

Connect the power sensor as shown in Figure 15-40.

Figure 15-40 Connecting power sensor

7. Measuring Calibration Data

Follow this step to measure the calibration data:

Setting Description Key Operation

Measuring calibration data

- Power Calibration - Take Cal Sweep
