250 Chapter 5
Making Measurements
Executing a Trigger Only for Active Channel
Executing a Trigger Only for Active Channel
Follow the procedure below to set the effective range of a trigger.
Procedure to set the range
Step 1. Press .
Step 2. Press Trigger Scope.
Softkey Function
All Channel A trigger is executed for all channels.
Active Channel A trigger is executed only for the active channel.
NOTE When you set the effective range of a trigger to “Active Channel” when the trigger mode is
continuous sweep mode (INIT:CONT:ON), the channel to be triggered is changed only by
swtching channels.
