490 Chapter 15

Measurement Examples

Measuring the SAW Bandpass Filter Using the Segment Sweep

3. Select the Segment Sweep as the Sweep Type

The segment sweep is selected as the sweep type.

Setup Description Key Operation

Sweep type: Segment sweep

- Sweep Type - Segment

4. Execute the Calibration

In this step, a 2-port ECal is executed on the two ports to be used.

Step 1. Connect the ECal module across test ports 1 and 2.

Figure 15-3 Connecting the ECal module

Step 2. Execute the 2-port ECal.

Setup Description Key Operation

Executing a 2-port ECal between test ports 1

and 2

- ECal - 2 Port ECal - 1-2
