Chapter 3 69

Setting Measurement Conditions

Setting the System Z0

3. Setting Measurement

Conditions

Setting the System Z0

NOTE This function is available with the firmware version 3.01 or greater.

The procedure for setting the system characteristic impedance (Z0) is as follows:

Step 1. Press .

Step 2. Press Set Z0.

Step 3. Enter the system Z0 using the ENTRY block keys on the front panel.
