502 Chapter 15
Measurement Examples
Evaluating a Duplexer
Step 2. Enter the setup data in the limit table for trace 1 (Figure 15-16).
Figure 15-16 Completed limit table for trace 1
Step 3. Display the limit table for Trace 2 (S
21
).
Setup Description Key Operation
Activating Trace 2
Step 4. Enter the setup data in the limit table for trace 2 (Figure 15-17).
Figure 15-17 Completed limit table for trace 2
11. Execute the Limit Test
The limit test is executed.
Step 1. Turn on the limit line and limit test for Trace 1.
Setup Description Key Operation
Activating Trace 1
Limit Line: ON
- Limit Test - Limit Line (Turn it ON)
Limit Test: ON Limit Test (Turn it ON)
To Next Page
