Agilent Technologies ENA Series

Chapter 16 555
Specifications and Supplemental Information
Measurement Throughput Summary
16. Specifications and
Supplemental Information
Measurement Throughput Summary
Table 16-20 Typical Cycle Time for Measurement Completion (ms)
*1*2
*1.Typical performance.
Number of Points
51 201 401 1601
Start 1 GHz, Stop 1.2 GHz, 100 kHz IF bandwidth
Uncorrected 4 5 7 18
2-port cal 5 8 13 42
Start 300 kHz, Stop 3 GHz, 100 kHz IF bandwidth
Uncorrected 11 12 13 23
2-port cal 20 23 25 46
Start 300 kHz, Stop 8.5 GHz, 100 kHz IF bandwidth
Uncorrected 19 24 24 24
2-port cal 37 46 48 50
Table 16-21 Typical Cycle Time for Measurement Completion (ms)
*1*2
*1.Typical performance.
Number of Points
51 201 401 1601
Start 1 GHz, Stop 1.2 GHz, 100 kHz IF bandwidth
Uncorrected 4 6 8 22
2-port cal 5 10 16 56
Start 300 kHz, Stop 3 GHz, 100 kHz IF bandwidth
Uncorrected 11 12 13 23
2-port cal 20 24 25 55
Start 300 kHz, Stop 8.5 GHz, 100 kHz IF bandwidth
Uncorrected 20 24 24 26
2-port cal 37 46 47 57
*2.Sweep mode: Fast swept. Analyzer display turned off with :DISP:ENAB OFF. Number of traces = 1. System error
correction: OFF.
*2.Sweep mode: Fast swept. Analyzer display turned off with :DISP:ENAB OFF. Number of traces = 1. System error
correction: ON.
