Chapter 15 519

Measurement Examples

Measuring Parameters with Cable

15. Measurement Examples

3. Connecting the DUT

Connect the DUT as shown in Figure 15-32.

Figure 15-32 Connecting the DUT

4. Auto Scale

Execute the auto scale function.

Setting Description Key Operation

Executing auto scale

- Auto Scale

Figure 15-33 Response in frequency domain
