Chapter 13 429
Setting and Using the Control and Management Functions
Setting the Internal Clock
13.Setting and Using the
Control and Management
Functions
Setting the Internal Clock
The E5070B/E5071B has the built-in clock that keeps track of the date and time. This
clock is used for the following functions.
• To display the current date and time in the instrument status bar at the lower part of the
screen
• To write date and time information when saving internal data or a VBA program
Setting the Date and Time
Step 1. Press .
Step 2. Press Misc Setup.
Step 3. Press Clock Setup.
Step 4. Press Set Date and Time.
The dialog box in Figure 13-4 appears.
Figure 13-4 Date/Time Properties Dialog Box (“Date & Time” Tab)
Step 5. Set the date in the Date area, and set the time in the Time area.
Step 6. Press the Time Zone tab.
The dialog box in Figure 13-5 appears.
To Next Page
