282 Chapter 7
Fixture Simulator
Overview of Fixture Simulator
Overview of Fixture Simulator
The fixture simulator is a function that uses software in the E5070B/E5071B to simulate
various measurement conditions based on the measurement results. The six functions are
as follows.
• Network de-embedding
• Port reference impedance conversion
• Matching circuit embedding
• 4-port network embedding/de-embedding
• Balance-unbalance conversion
*1
• Differential/Common port reference impedance conversion
*1
• Differential matching circuit embedding
*1
Figure 7-1 shows the data processing flow diagram of the fixture simulator.
Figure 7-1 Data processing flow diagram of fixture simulator
*1.Option 313, 314, 413, or 414 only.
