Appendix D 703
Softkey Functions
Measurement Menu (Balance Measurement, SE-Bal)
D. Softkey Functions
Measurement Menu (Balance Measurement, SE-Bal)
Key Operation Function SCPI Command
Displays softkeys for setting measurement parameters (only for models with Option 313, 314, 413, or 414). To
display these softkeys, the balanced/unbalanced conversion topology must be set to unbalanced-balanced
(
SE-Bal), the balanced/unbalanced conversion function must be on (BalUn ON), and the fixture simulator function
must be on (
Fixture Simulator ON) in the “Analysis Menu” on page 647.
Sss11 Selects parameter S
ss11
. S
ss11
defines the way an unbalanced
signal input to (unbalanced) port 1 on the DUT is reflected as an
unbalanced signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:SBAL SSS11
Sds21 Selects parameter S
ds21
. S
ds21
defines the way an unbalanced
signal input to (unbalanced) port 1 on the DUT is transmitted to
(balanced) port 2 on the DUT as a differential signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:SBAL
SDS21
Ssd12 Selects parameter S
sd12
. S
sd12
defines the way a differential
signal input to (balanced) port 2 on the DUT is transmitted to
(unbalanced) port 1 on the DUT as an unbalanced signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:SBAL
SSD12
Scs21 Selects parameter S
cs21
. S
cs21
defines the way an unbalanced
signal input to (unbalanced) port 1 on the DUT is transmitted to
(balanced) port 2 on the DUT as a common mode signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:SBAL
SCS21
Ssc12 Selects parameter S
sc12
. S
sc12
defines the way a common mode
signal input to (balanced) port 2 on the DUT is transmitted to
(unbalanced) port 1 on the DUT as an unbalanced signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:SBAL
SSC12
Sdd22 Selects parameter S
dd22
. S
dd22
defines the way a differential
signal input to (balanced) port 2 on the DUT is reflected as a
differential signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:SBAL
SDD22
Scd22 Selects parameter S
cd22
. S
cd22
defines the way a differential
signal input to (balanced) port 2 on the DUT is reflected as a
common mode signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:SBAL
SCD22
Sdc22 Selects parameter S
dc22
. S
dc22
defines the way a common mode
signal input to (balanced) port 2 on the DUT is reflected as a
differential signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:SBAL
SDC22
Scc22 Selects parameter S
cc22
. S
cc22
defines the way a common mode
signal input to (balanced) port 2 on the DUT is reflected as a
common mode signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:SBAL
SCC22
Imbalance Selects parameter Imbalance.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:SBAL IMB
Sds21/Scs21 Selects parameter Sds21/Scs21.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:SBAL CMRR
Ssd12/Ssc12 Selects parameter Ssd12/Ssc12.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:SBAL
CMRR2
Return Returns to the “E5070B/E5071B Menu (Top Menu)” on page 646.
