704 Appendix D
Softkey Functions
Measurement Menu (Balanced Measurement, Bal-Bal)
Measurement Menu (Balanced Measurement, Bal-Bal)
Key Operation Function SCPI Command
Displays softkeys for setting up measurement parameters (only for models with Option 412 or 414). To display
these softkeys, the balanced/unbalanced conversion topology must be set to balanced-balanced (
Bal-Bal), the
balanced/unbalanced conversion function must be on (
BalUn ON), and the fixture simulator function must be on
(
Fixture Simulator ON) in the “Analysis Menu” on page 647.
Sdd11 Selects parameter S
dd11
. S
dd11
defines the way a differential
signal input to (balanced) port 1 on the DUT is reflected as a
differential signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:BBAL
SDD11
Sdd21 Selects parameter S
dd21
. S
dd21
defines the way a differential
signal input to (balanced) port 1 on the DUT is transmitted to
(balanced) port 2 on the DUT as a differential signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:BBAL
SDD21
Sdd12 Selects parameter S
dd12
. S
dd12
defines the way a differential
signal input to (balanced) port 2 on the DUT is transmitted to
(balanced) port 1 on the DUT as a differential signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:BBAL
SDD12
Sdd22 Selects parameter S
dd22
. S
dd22
defines the way a differential
signal input to (balanced) port 2 on the DUT is reflected as a
differential signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:BBAL
SDD22
Scd11 Selects parameter S
cd11
. S
cd11
defines the way a differential signal
input to (balanced) port 1 on the DUT is reflected as a common
mode signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:BBAL
SCD11
Scd21 Selects parameter S
cd21
. S
cd21
defines the way a differential
signal input to (balanced) port 1 on the DUT is transmitted to
(balanced) port 2 on the DUT as a common mode signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:BBAL
SCD21
Scd12 Selects parameter S
cd12
. S
cd12
defines the way a differential
signal input to (balanced) port 2 on the DUT is transmitted to
(balanced) port 1 on the DUT as a common mode signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:BBAL
SCD12
Scd22 Selects parameter S
cd22
. S
cd22
defines the way a differential
signal input to (balanced) port 2 on the DUT is reflected as a
common mode signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:BBAL
SCD22
Sdc11 Selects parameter S
dc11
. S
dc11
defines the way a common mode
signal input to (balanced) port 1 on the DUT is reflected as a
differential signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:BBAL
SDC11
Sdc21 Selects parameter S
dc21
. S
dc21
defines the way a common mode
signal input to (balanced) port 1 on the DUT is transmitted to
(balanced) port 2 on the DUT as a differential signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:BBAL
SDC21
Sdc12 Selects parameter S
dc12
. S
dc12
defines the way a common mode
signal input to (balanced) port 2 on the DUT is transmitted to
(balanced) port 1 on the DUT as a differential signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:BBAL
SDC12
Sdc22 Selects parameter S
dc22
. S
dc22
defines the way a common mode
signal input to (balanced) port 2 on the DUT is reflected as a
differential signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:BBAL
SDC22
Scc11 Selects parameter S
cc11
. S
cc11
defines the way a common mode
signal input to (balanced) port 1 on the DUT is reflected as a
common mode signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:BBAL
SCC11
Scc21 Selects parameter S
cc21
. S
cc21
defines the way a common mode
signal input to (balanced) port 1 on the DUT is transmitted to
(balanced) port 2 on the DUT as a common mode signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:BBAL
SCC21
Scc12 Selects parameter S
cc12
. S
cc12
defines the way a common mode
signal input to (balanced) port 2 on the DUT is transmitted to
(balanced) port 1 on the DUT as a common mode signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:BBAL
SCC12
