Agilent Technologies ENA Series

Appendix D 705
Softkey Functions
Measurement Menu (Balanced Measurement, Bal-Bal)
D. Softkey Functions
(Continued)
Scc22 Selects parameter S
cc22
. S
cc22
defines the way a common mode
signal input to (balanced) port 2 on the DUT is reflected as a
common mode signal.
:CALC{1-16}:FSIM:BAL:PAR{1-16}: BBAL
SCC22
Imbalance1 Selects parameter Imbalance1.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:BBAL IMB1
Imbalance2 Selects parameter Imbalance2.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:BBAL IMB2
Sdd21/Scc21 Selects parameter Sdd21/Scc21.
:CALC{1-16}:FSIM:BAL:PAR{1-16}:BBAL
CMRR
Return Returns to the “E5070B/E5071B Menu (Top Menu)” on page 646.
Key Operation Function SCPI Command
