708 Appendix D

Softkey Functions

Preset Menu

Key Operation Function SCPI Command

Displays softkeys for restoring the preset conditions.

OK Restores the preset conditions.

:SYST:PRES

Cancel Returns to the “E5070B/E5071B Menu (Top Menu)” on page 646.
