Chapter 15 489

Measurement Examples

Measuring the SAW Bandpass Filter Using the Segment Sweep

15. Measurement Examples

Figure 15-2 Completed segment table

Number of points: 55

IF bandwidth: 70 kHz

Segment 4

Start frequency: 1.07 GHz

Stop frequency: 2 GHz

Number of points: 93

IF bandwidth: 70 kHz

Segment 5

Start frequency: 2.6 GHz

Stop frequency: 3 GHz

Number of points: 41

IF bandwidth: 70 kHz
