408 Chapter 12

Optimizing Measurements

Setting Port Extensions and Loss Values

NOTE If you execute both open measurement and short measurement, the average of the

calculation results is reflected to the port extension and loss value.

6. Deleting the result of open/short measurement

When you exit from the softkey menu in the same level after open/short measurement, the

measurement results are deleted. Note that you can use a GPIB command.

NOTE Port extension and loss values that have been calculated are not cleared.
