Fixture Simulator
Converting Reference Impedance of Balanced Port
to set the differential port reference impedance in “Real” format.
• Select Port 1 (bal) Real and Port 1 (bal) Imag, Port 2 (bal) Real and Port2 (bal) Imag,
or
Port 3 (bal) Real and Port 3 (bal) Imag to set the common port reference impedance
in “Complex” format.
NOTE Ports1, 2, and 3 refer to the logical ports 1, 2, and 3.
