Chapter 10 353
Data Output
Saving and Recalling Instrument State
10. Data Output
R Compatibility between models that have different options (number of ports and power
range expansion)
• If the stored data is “state only (State Only),” files saved with a model having a
smaller number of ports can be recalled with a model having a larger number of
ports, but the opposite is not possible.
• Files saved with a model not having the power range expansion feature can be
recalled with a model having the power range expansion feature, but the opposite is
not possible.
Recalling
Power range expansion Without With
Number of ports 2 3 4 2 3 4
Option number 213 313 413 214 314 414
Saved
file
Without 2 213 Y Y/c Y/c Y Y/c Y/c
3 313 N Y Y/c N Y Y/c
4 413 N N Y N N Y
With 2 214 N N N Y Y/c Y/c
3 314 N N N N Y Y/c
4 414 N N N N N Y
Y: Recall is possible. N: Recall is impossible.
Y/c: Only when the stored data is “state only (State Only),” recall is possible.
R Compatibility when the maximum number of channels/traces is different
• You cannot recall files saved by specifying all channels/traces (All) as the save
target.
• If the number channels/traces at recall does not exceed that at save, you cannot
recall files saved by specifying the displayed channel/trace (
Disp Only) as the save
target.
R Compatibility when the firmware version is different
• Files that are saved with later firmware versions cannot be recalled by prior
firmware versions.
• Because Auto Power Range set function is added in firmware version 3.60, when
recalling files that are saved with lower firmware versions, Auto Power Range set
function is turned on with 3.60 and above firmware versions.
*1
• When Files that are saved with 3.54 and below include calibration data, only states
and trace data are recalled with 3.60 and later firmware versions.
R Compatibility when the system spec. version (available with “:SERV:SREV?”) is
different
Y: Recall is possible. N: Recall is impossible.
*1.Includes E5070A equipped with power sweep feature.
*2.Includes E5071A equipped with power sweep feature.
*1.Except for options 213, 313, and 413.
