406 Chapter 12
Optimizing Measurements
Setting Port Extensions and Loss Values
3. Specifying a loss value as a calculation target
Specify whether you want to include a loss value in the calculation result.
Step 1. Press or to activate the channel for which you want to set auto
port extension.
Step 2. Press .
Step 3. Press Port Extensions.
Step 4. Press Auto Port Extension.
Step 5. Press Include Loss to turn it on.
Softkey Function
ON Calculates a loss value.
OFF Does not calculate a loss value.
NOTE If the setting is not made before starting the measurement of the OPEN/SHORT standard, it
does not affect the calculation result.
4. Specifying a DC loss value as a calculation target
Specify whether you want to include a DC loss value in the calculation result.
Step 1. Press or to activate the channel for which you want to set auto
port extension.
Step 2. Press .
Step 3. Press Port Extensions.
Step 4. Press Auto Port Extension.
Step 5. Press Adjust Mismatch to turn it on.
Softkey Function
ON Calculates a DC loss value.
OFF Does not calculate a DC loss.
NOTE If the setting is not made before starting the measurement of the OPEN/SHORT standard, it
does not affect the calculation result.
