422 Chapter 12
Optimizing Measurements
Performing a Segment-by-Segment Sweep (segment sweep)
Executing segment sweep
To execute a segment sweep by using the segment table you have created, you must specify
the sweep type for that sweep operation by following the steps below.
Step 1. Press (or ) to select the channel on which you will execute the
segment sweep operation.
Step 2. Press .
Step 3. Press Sweep Type.
Step 4. Press Segment.
Setting up the segment display
Define the method of displaying traces when the segment sweep is executed by following
the steps described below.
Step 1. Press (or ) to select the channel on which you will define the
segment display.
Step 2. Press .
Step 3. Press Segment Display.
Step 4. Select the segment display.
Softkey Function
Freq Base Displays the X-axis as the axis for linear frequencies (frequency-based
display)
Order Base Displays the X-axis as the axis for the points (order-based display)
