48 Chapter 2
Overview of Functions
Screen Area: Names and Functions of Parts
5-5. Trace Status Area
The setup for each trace is displayed here.
Table 2-1 Trace status display
Classification Contents inside [ ] Meaning
Error correction RO Error correction: ON (OPEN (n) response calibration)
RS Error correction: ON (SHORT (n) response calibration)
RT Error correction: ON (THRU (n) response calibration)
ER Error correction: ON (Enhanced response calibration)
F1 Error correction: ON (1-port calibration )
F2 Error correction: ON (Full 2-port calibration / 2-port TRL
calibration)
F3 Error correction: ON (Full 3-port calibration / 3-port TRL
calibration)
F4 Error correction: ON (Full 4-port calibration / 4-port TRL
calibration)
Turning on/off traces Nothing Data trace: ON, Memory trace: OFF
M Data trace: OFF, Memory trace: ON
D&M Data trace: ON, Memory trace: ON
off Data trace: OFF, Memory trace: OFF
Performing data math D+M (D+M&M) Execution of Data+Mem math
D−M (D−M&M) Execution of Data−Mem math
D*M (D*M&M) Execution of Data*Mem math
D/M (D/M&M) Execution of Data/Mem math
Electrical delay Del A numeric value other than 0 (zero) is specified as the
electrical delay or phase offset.
Smoothing Smo Smoothing: ON
Gating Gat Gating: ON
Parameter conversion Zr Conversion: ON (Impedance: Reflection measurement)
Zt Conversion: ON (Impedance: Transmission measurement)
Ztsh Conversion: ON (Impedance: Transmission-Shunt
measurement)
Yr Conversion: ON (Admittance: Reflection measurement)
Yt Conversion: ON (Admittance: Transmission measurement)
Ytsh Conversion: ON (Admittance: Transmission-Shunt
measurement)
1/S Conversion: ON (Inverse S-parameter)
Conj Conversion: ON (Conjugation)
Power correction PC Error correction: ON (Power calibration)
Receiver correction RC Error correction: ON (Receiver calibration)
Scalar-mixer
correction
Cor Error correction: ON (Scalar-mixer calibration)
