Test Port Output (Source)
Level Linearity (high temperature mode: ON)
300 kHz to 3 GHz
3 GHz to 4.25 GHz
4.25 GHz to 6 GHz
6 GHz to 8.5 GHz
±1.5 dB (at −15 dBm to 10 dBm)
±1.5 dB (at −15 dBm to 9 dBm)
±2.0 dB (at −15 dBm to 7 dBm)
±2.0 dB (at −15 dBm to 5 dBm)
Level Linearity (swept mode)
300 kHz to 3 GHz
3 GHz to 4.25 GHz
4.25 GHz to 6 GHz
6 GHz to 8.5 GHz
±1.5 dB (at −15 dBm to 10 dBm)
±1.5 dB (at −15 dBm to 9 dBm)
±3 dB (at −15 dBm to 7 dBm)
±3 dB (at −15 dBm to 5 dBm)
Range
(Source attenuator 0 dB)
300 kHz to 3 GHz
3 GHz to 4.25 GHz
4.25 GHz to 6 GHz
6 GHz to 8.5 GHz
300 kHz to 3 GHz
3 GHz to 4.25 GHz
4.25 GHz to 6 GHz
6 GHz to 8.5 GHz
−15 dBm to 10 dBm
−15 dBm to 9 dBm
−15 dBm to 7 dBm
−15 dBm to 5 dBm
−50 dBm to 10 dBm
−50 dBm to 9 dBm
−50 dBm to 7 dBm
−50 dBm to 5 dBm
(non-harmonics spurious may
limit power range)
Sweep Range (Source attenuator 0 dB)
300 kHz to 3 GHz
3 GHz to 4.25 GHz
4.25 GHz to 6 GHz
6 GHz to 8.5 GHz
−15 dBm to 10 dBm
−15 dBm to 9 dBm
−15 dBm to 7 dBm
−15 dBm to 5 dBm
−20 dBm to 10 dBm
−20 dBm to 9 dBm
−20 dBm to 7 dBm
−20 dBm to 5 dBm
Level Resolution 0.05 dB
Table 16-9 Test Port Output Signal Purity
Description Specification Supplemental Information
Harmonics (2nd or 3rd)
10 MHz to 2 GHz
2 GHz to 3 GHz
3 GHz to 8.5 GHz
< −25 dBc (at 5 dBm, typical)
< −15 dBc (at 5 dBm, typical)
< −10 dBc (at 5 dBm, typical)
Non-Harmonic Spurious
10 MHz to 3 GHz
3 GHz to 8.5 GHz
< −25 dBc (at 5 dBm, typical)
< −10 dBc (at 5 dBm, typical)
*1.Source output performance on port 1 only. Other port output performance is typical.
Table 16-8 Test Port Output Power
*1
Description Specification Supplemental Information
