Chapter 17 567

Measurement Accessories

Calibration Kits

17. Measurement Accessories

Coaxial Electronic Calibration Kits

85092C RF Two-Port ECal Module (300 kHz ~ 9 GHz)

Option Description

Option M0F Module with 50 Ω N type (m)/N type (f) connectors

Option 00M Module with 50 Ω N type (m)/N type (m) connectors

Option 00F Module with 50 Ω N type (f)/N type (f) connectors

N4431A RF Four-Port ECal Module (300 kHz ~ 9 GHz)

Option Description

Option 020 Module with four 50 Ω N type (f) connectors
