640 Appendix C

List of Default Values

List of Default Values, Save/Recall Settings, and Backup Settings

Limit Test

Limit Line Offsets

Stimulus Offset 0Hz ← ← √ K/C

Amplitude

Offset

0Hz ← ← √ K/C

Fail Sign ON ← ← √ K/C

Ripple Limit

Ripple Limit Test OFF ← ← √ K/C

Ripple Limit OFF ← ← √ K/C

Ripple Value OFF ← ← √ K/C

Ripple Band 1 ← ← √ K/C

Fail Sign ON ← ← √ K/C

Bandwidth Limit

BW Test OFF ← ← √ K/C

BW Display OFF ← ← √ K/C

BW Marker OFF ← ← √ K/C

N dB Points 0dB ← ← √ K/C

Min Bandwidth 0Hz ← ← √ K/C

Max Bandwidth 0Hz ← ← √ K/C

Fail Sign ON ← ← √ K/C

Echo Window OFF ← ← √ K/C

Save Type State&Cal ← ← √ K/C

Channel/Trace Disp Only ← ← √ K/C

Save SnP

SnP Format Auto ← ← √ K/C

Key Operation Factory-shipped Setting Default Value Save/

Recall

Backup Available

Means of

Defining a

Setting

*RST
