648 Appendix D
Softkey Functions
Analysis Menu
(Continued)
Fixture Simulator
Topology
*1
Port1 (bal)
*2
2-3 Selects test ports 2 and 3 on the analyzer for connection with (balanced)
port 1 on the DUT (ports a and b in
Table 7-8 on page 294) respectively.
:CALC{1-16}:FSIM:BAL:TOP:BBAL
2-4 Selects test ports 2 and 4 on the analyzer for connection with (balanced)
port 1 on the DUT (ports a and b in
Table 7-8 on page 294) respectively.
:CALC{1-16}:FSIM:BAL:TOP:BBAL
3-1 Selects test ports 3 and 1 on the analyzer for connection with (balanced)
port 1 on the DUT (ports a and b in
Table 7-8 on page 294) respectively.
:CALC{1-16}:FSIM:BAL:TOP:BBAL
3-2 Selects test ports 3 and 2 on the analyzer for connection with (balanced)
port 1 on the DUT (ports a and b in
Table 7-8 on page 294) respectively.
:CALC{1-16}:FSIM:BAL:TOP:BBAL
3-4 Selects test ports 3 and 4 on the analyzer for connection with (balanced)
port 1 on the DUT (ports a and b in
Table 7-8 on page 294) respectively.
:CALC{1-16}:FSIM:BAL:TOP:BBAL
4-1 Selects test ports 4 and 1 on the analyzer for connection with (balanced)
port 1 on the DUT (ports a and b in
Table 7-8 on page 294) respectively.
:CALC{1-16}:FSIM:BAL:TOP:BBAL
4-2 Selects test ports 4 and 2 on the analyzer for connection with (balanced)
port 1 on the DUT (ports a and b in
Table 7-8 on page 294) respectively.
:CALC{1-16}:FSIM:BAL:TOP:BBAL
Cancel Returns to the softkey display screen one level higher.
4-3 Selects test ports 4 and 3 on the analyzer for connection with (balanced)
port 1 on the DUT (ports a and b in
Table 7-8 on page 294) respectively.
:CALC{1-16}:FSIM:BAL:TOP:BBAL
Port2 (bal) Displays softkeys for selecting the analyzer ports (test ports) to which (balanced) port 2 on the DUT will be
connected. This key will be displayed only when
SE-Bal or Bal-Bal in the Device menu is selected.
1-2 Selects test ports 1 and 2 on the analyzer for connection with (balanced)
port 2 on the DUT (ports b and c for
SE-Bal or ports c and d for Bal-Bal in
Table 7-8 on page 294) respectively.
:CALC{1-16}:FSIM:BAL:TOP:BBAL
:CALC{1-16}:FSIM:BAL:TOP:SBAL
1-3 Selects test ports 1 and 3 on the analyzer for connection with (balanced)
port 2 on the DUT (ports b and c for
SE-Bal or ports c and d for Bal-Bal in
Table 7-8 on page 294) respectively.
:CALC{1-16}:FSIM:BAL:TOP:BBAL
:CALC{1-16}:FSIM:BAL:TOP:SBAL
1-4
*2
Selects test ports 1 and 4 on the analyzer for connection with (balanced)
port 2 on the DUT (ports b and c for
SE-Bal or ports c and d for Bal-Bal in
Table 7-8 on page 294) respectively.
:CALC{1-16}:FSIM:BAL:TOP:BBAL
:CALC{1-16}:FSIM:BAL:TOP:SBAL
2-1 Selects test ports 2 and 1 on the analyzer for connection with (balanced)
port 2 on the DUT (ports b and c for
SE-Bal or ports c and d for Bal-Bal in
Table 7-8 on page 294) respectively.
:CALC{1-16}:FSIM:BAL:TOP:BBAL
:CALC{1-16}:FSIM:BAL:TOP:SBAL
2-3 Selects test ports 2 and 3 on the analyzer for connection with (balanced)
port 2 on the DUT (ports b and c for
SE-Bal or ports c and d for Bal-Bal in
Table 7-8 on page 294) respectively.
:CALC{1-16}:FSIM:BAL:TOP:BBAL
:CALC{1-16}:FSIM:BAL:TOP:SBAL
2-4
*2
Selects test ports 2 and 4 on the analyzer for connection with (balanced)
port 2 on the DUT (ports b and c for
SE-Bal or ports c and d for Bal-Bal in
Table 7-8 on page 294) respectively.
:CALC{1-16}:FSIM:BAL:TOP:BBAL
:CALC{1-16}:FSIM:BAL:TOP:SBAL
3-1 Selects test ports 3 and 1 on the analyzer for connection with (balanced)
port 2 on the DUT (ports b and c for
SE-Bal or ports c and d for Bal-Bal in
Table 7-8 on page 294) respectively.
:CALC{1-16}:FSIM:BAL:TOP:BBAL
:CALC{1-16}:FSIM:BAL:TOP:SBAL
3-2 Selects test ports 3 and 2 on the analyzer for connection with (balanced)
port 2 on the DUT (ports b and c for
SE-Bal or ports c and d for Bal-Bal in
Table 7-8 on page 294) respectively.
:CALC{1-16}:FSIM:BAL:TOP:BBAL
:CALC{1-16}:FSIM:BAL:TOP:SBAL
3-4
*2
Selects test ports 3 and 4 on the analyzer for connection with (balanced)
port 2 on the DUT (ports b and c for
SE-Bal or ports c and d for Bal-Bal in
Table 7-8 on page 294) respectively.
:CALC{1-16}:FSIM:BAL:TOP:BBAL
:CALC{1-16}:FSIM:BAL:TOP:SBAL
Key Operation Function SCPI Command
