680 Appendix D
Softkey Functions
Calibration Menu
(Continued)
Modify Cal Kit
Specify CLSs
Thru Displays softkeys for setting the THRU standard class.
Set All Displays softkeys for selecting standard for the THRU standard class that applies to all test ports.
None Does not include 1. (Std Name) in the THRU standard class.
:SENS{1-16}:CORR:COLL:CKIT:ORD:THRU
x,y,0
1. (Std
Name)
Includes 2. (Std Name) in the THRU standard class.
:SENS{1-16}:CORR:COLL:CKIT:ORD:THRU
x,y,1
.
.
.
.
.
.
21. (Std
Name)
Includes 21.( Std Name) in the THRU standard class.
:SENS{1-16}:CORR:COLL:CKIT:ORD:THRU
x,y,21
Cancel Returns to the softkey display screen one level higher.
Port 1-2 Displays softkeys for selecting standards for the THRU standard class that applies to test ports 1 and 2. The
lower-level softkeys are the same as those for
Set All.
Port 1-3 Displays softkeys for selecting standards for the THRU standard class that applies to test ports 1 and 3. The
lower-level softkeys are the same as those for
Set All.
Port 1-4 Displays softkeys for selecting standards for the THRU standard class that applies to test ports 1 and 4. The
lower-level softkeys are the same as those for
Set All.
Port 2-3 Displays softkeys for selecting standards for the THRU standard class that applies to test ports 2 and 3. The
lower-level softkeys are the same as those for
Set All.
Port 2-4 Displays softkeys for selecting standards for the THRU standard class that applies to test ports 2 and 4. The
lower-level softkeys are the same as those for
Set All.
Port 3-4 Displays softkeys for selecting standards for the THRU standard class that applies to test ports 3 and 4. The
lower-level softkeys are the same as those for
Set All.
Return Returns to the softkey display screen one level higher.
TRL Thru Displays softkeys for setting the TRL THRU standard. The
lower-level softkeys displayed are the same as those for
Thru.
:SENS{1-16}:CORR:COLL:CKIT:ORD:TRLT
TRL Reflect
None Does not include 1. (Std Name) in the TRL reflection standard class.
:SENS{1-16}:CORR:COLL:CKIT:ORD:TRLR 0
1. (Std Name) Includes 1. (Std Name) in the TRL reflection standard class.
:SENS{1-16}:CORR:COLL:CKIT:ORD:TRLR 1
.
.
.
.
.
.
21. (Std
Name)
Includes 21. (Std Name) in the TRL reflection standard class.
:SENS{1-16}:CORR:COLL:CKIT:ORD:TRLR
21
Cancel Returns to the softkey display screen one level higher.
TRL Line/Match Displays softkeys for setting the TRL LINE/MATCH standard. The
lower-level softkeys displayed are the same as those for
Thru.
:SENS{1-16}:CORR:COLL:CKIT:ORD:TRLL
Return Returns to the softkey display screen one level higher.
TRL Option Displays softkeys for setting the TRL calibration.
Impedance Selects the reference impedance.
:SENS{1-16}:CORR:COLL:CKIT:TRL:IMP
Reference Plane Selects the measurement data for the standard used to calculate the
reference plane.
:SENS{1-16}:CORR:COLL:CKIT:TRL:RPL
Return Returns to the softkey display screen one level higher.
Key Operation Function SCPI Command
