694 Appendix D

Softkey Functions

Macro Setup Menu

(Continued)

User Menu

Button 10 Executes the procedure assigned to Button 10. Softkey label can be

modified using a command.

None

Return Returns to the softkey display screen one level higher.

Preset User Menu Returns the softkey labels of user menu to the initial settings. None

Return Returns to the “E5070B/E5071B Menu (Top Menu)” on page 646.
