Commonly Used Procedures 6
Agilent Nano Indenter G200 User’s Guide 6-28
6 Use forceps or tweezers to remove the tip from retaining nut as
shown in
Figure 6-41.
Figure 6-41Use tweezers to remove indenter tip
7 Reverse step 6 to install the indenter into the retaining nut.
Figure 6-42Handle indenter tip only by Tip Tab as circled in red
Use care when handling the tip. Do not touch the diamond tip with any
object. A dirty indenter can cause corrupted data, so pick up the indenter
by the Indenter Tip Tab only, as shown in
Figure 6-42.
