Dynamic Contact Module II B
Agilent Nano Indenter G200 User’s Guide B-11
Figure B-15Insert locking pins halfway through the head
3 Slide the DCM II Tip Change Guide Tool onto the head shaft being
careful to align the protruding locking pins with the slots in the guide
tool as shown in
Figure B-16.
Figure B-16DCM II tip change tool guide
Use extreme care to prevent damage.
