Dynamic Contact Module II B
Agilent Nano Indenter G200 User’s Guide B-13
Figure B-18First turn wrench counterclockwise (left) then slowly slide
wrench and guide tool down (right)
The tip floats freely in the micro-socket wrench, so keep the tool in a
vertical orientation (
Figure B-19) when removing or replacing the tip to
avoid dropping the tip.
Figure B-19Keep wrench vertical when removing or replacing tip
7 Use tweezers to remove the tip from, or install the new tip into, the
micro-socket wrench.
