Ashida ADR233B - Page 10

ADR233B
Doc ID : ADR233B/IM/01
Ref ID : ADR233B/IM/ToC
Rev No. : 05
Page No. : 10 of 479
Table of Contents
Section 1 : Introduction and Specifications
Sr. No. Description Page No.
1 Introduction and Specifications 26
1.1 Overview 26
1.2 Features 26
1.3 TECHNICAL SPECIFICATIONS 32
1.4 Typical Tests Information 38
Section 2 : Installation and Procedure
Sr. No. Description Page No.
2 INSTALATION PROCEDURE 43
2.1 Overview 43
2.2 Handling 43
2.2.1 Handling the Goods 43
2.2.2 Receipt of the Goods 43
2.2.3 Unpacking the Goods 43
2.2.4 Storing the Goods 43
2.2.5 Dismantling the Goods 44
2.3 Installation Procedure 44
2.3.1 Safe Mounting of Modular version 44
2.3.2 Safe Mounting of Enhanced and Basic version 45
2.3.3 Relay Connection and Diagram 47
2.3.4 Before Energizing following things should be checked 47
2.3.5 Relay Operating Condition 48
2.3.6 Current Transformer (CT) Circuit 48
2.3.7 Insulation and dielectric strength testing 48
2.3.8 Cables and Connectors 48
2.3.9 Power Supply Connections 52
2.3.10 Earth Connection 53
2.4 Dimensions and Electrical Connection 54
2.4.1 Mechanical Details – Basic Model 54
