ADR233B
W2 – Ic RMS :
0.00 A
V:
0.00 V
This window shows RMS Current in Phase C and Primary
Voltage of Winding 2 (W2).
Press the Minus / Down arrow key (- /) to move to the next
option.
v:
0.00 V
Frequency :
0.00 Hz
This window shows Secondary Voltage and Frequency of
power system.
Press the Minus / Down arrow key (- /) to move to the next
option.
V/Hz :
0.00
Th State :
0 %
This window shows the ratio of Voltage to Frequency of power
system and Actual Thermal state.
Press the Right arrow key () to move to the Main Menu
MEASURMENTS

GLOBAL
CB CONTOL
REPORTING
8.4.3.2 To View – Measurement 2
MEASURMENTS

GLOBAL
CB CONTOL
REPORTING
This menu is to view Measurements i.e. Measurement 1 and
Measurement 2.
Press the Right arrow key () to move to the next option.
Measurement 1
Measurement 2

By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Measurement 2. (This menu is to
view Measurement 2).
Press the Right arrow key () to move to the next option.
IA – Bias :
0.00 pu
IA – Diff :
0.00 pu
This window will show Bias & Diff Current of Phase A
Press the Minus / Down arrow key (- /) to move to the next
option.
