Ashida ADR233B - Sequence OC; W1 Sequence OC (if Disabled)

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 356 of 479
ADR233B
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Note: The W1 Residual OC settings of 3Io>2 Enable and 3Io>3 Enable for Definite Time Curve is
similar to W1 Residual OC setting of 3Io>1 Enable.
Note: The Residual OC settings of W2 Residual OC is similar to W1 Residual OC.
8.4.11.8 Sequence OC
8.4.11.8.1 W1 Sequence OC (If Disabled)
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC, Ground
OC, Residual OC, Sequence OC, Under Voltage, Over
Voltage, V/Hz Protection, Breaker Failure, Thermal Overload
and Through Fault.
Press the Right arrow key () to move to the next option.
Phase OC
Ground OC
Residual OC
Sequence OC

Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Sequence OC.
Press the Right arrow key () to move to the next option.
Sequence OC
W1 Sequence OC

W2 Sequence OC
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select W1 Sequence OC.
Password protected window for “W1 Sequence OC” setting
i.e. Seq. I>1 Enable, Seq. I>2 Enable and Seq. I>3 Enable
can be set as Disabled / -Seq / +Seq.
