8.4.7 SYSTEM CONFIG
8.4.7.1 CT/VT Ratios – System Config.
GLOBAL
CB CONTOL
REPORTING
SYSTEM CONFIG

Password protected window for “System Config” setting i.e.
CT/VT Ratios.
Press the Right arrow key () to move to the next option.
SYSTEM CONFIG
CT/VT RATIO
Editable Setting
Password protected window for “CT/VT Ratio” setting i.e. W1
Ph CT Secondary, W1 Ph CT Primary, W2 Ph CT Secondary,
W2 Ph CT Primary, EF CT Secondary, EF CT Primary, CT
Star Point, VT Primary, VT Selection (Line to Line) and VT
Secondary and setting Values.
Press the Right arrow key () to move to the next option.
CT/VT RATIO
W1 Ph CT Secondary
1 A
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the W1 Ph CT Secondary can be set i.e.
1Amp. / 5Amp.
Press the Minus / Down arrow key (- /) to move to the next
option.
CT/VT RATIO
W1 Ph CT Primary
10 A
Range 10 – 5000A
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the W1 Ph CT Primary can be set.
The setting range is from 10 to 5000A in step of 1A.
Press the Minus / Down arrow key (- /) to move to the next
option.
