ADR233B
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

8.4.11.9.2 To Set – Under Voltage (If Enabled)
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1

Password protected window for “Group 1” setting. i.e.
Equipment Data, Ph Differential, REF, Phase OC, Ground
OC, Residual OC, Sequence OC, Under Voltage, Over
Voltage, V/Hz Protection, Breaker Failure, Thermal Overload
and Through Fault.
Press the Right arrow key () to move to the next option.
Ground OC
Residual OC
Sequence OC
Under Voltage

Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) select Under Voltage.
Press the Right arrow key () to move to the next option.
Under Voltage
Under Voltage SET

Enabled
Editable Setting
Password protected window for “Under Voltage SET” can be
set i.e. Disabled / Enabled.
Note: When set as Enabled.
Press the Right arrow key () to move to the next option.
